Can I Connect two AC2200 WiFi Mesh Extenders (EX7300)?

Nowadays, users install one router in 2-3 storied building. And the router is connected on the second one, so that the device reach can be divided into three floors. But it cannot provide signals into the three floors, you will get the signals on the second floor but on others the signals will be very weak.

So, to resolve the issue, user bring two extender and what to know how to connect both of them with the same router. Let’s solve this user query of “Can I connect two AC2200 in my home”.

Use One AC2200 Extender in Access Point Mode

Netgear EX7300 Multi-Extender Setup (First Extender in AP Mode)

1. Plug in Your Extender

Start by plugging your AC2200 extender into a power outlet near your router this makes initial setup easier. Power LED will turn solid green when electricity supplied. If it blinks or flashes orange, give it a minute.

2. Use the Ethernet Cable

Make use of that Ethernet cable and plug one end into your router, and the other end into the extender’s Ethernet port.

3. Access the Extender Settings Page

Connect with the extender’s default WiFi (Netgear_EXT) on your laptop or computer. Type: mywifiext.net or 192.168.1.250 in web browser and search it. You’ll land on the Netgear EX7300 multi-extender setup page. If it asks for login, the default is:

  • Username: admin
  • Password: password

4. Choose Access Point Mode

Click on “New Extender Setup”. Accept the terms, then create new credentials if prompted. You’ll be asked how you want to use the extender. Select Access Point Mode

At this point, the system will detect the Ethernet connection and proceed accordingly.

4. Configure Your AP Network

Name your AP WiFi network (SSID) – This can be the same as your main network, or a new one for clarity. You must set a strong password. select any of 2.4GHz and 5GHz bands for optimal performance. Next, hit Next or Finish. The extender will reboot, and the new access point network should be live within a few minutes.

5. Reconnect to the New Network

When the reboot process completes, you can connect your devices to the new AP network using the name and password you have just set.

Configure Second AC2200 Extender with WPS

  1. Pick a power outlet that’s not too far from your main extender but still closer to the area where your WiFi signal drops. Pick the spot about halfway between your first extender and the WiFi dead zone.
  2. The power LED on the AC2200 extender to turn solid when it is connected securely. Usually takes about 30 seconds.
  3. Find the WPS button on your extender connected with the router via cable. It’s usually labeled “WPS” and might be a small recessed button. Push it once. Extender’s WPS LED should start blinking green.
  4. Within two minutes of pressing the first extender’s (AP mode) WPS button, press the WPS button on your AC2200 extender. The WPS LED on the extender should begin to blink as well.
  5. The WPS LED on the extender will eventually turn solid. That’s your green light it’s now connected to your router.
  6. You might also see a signal strength light on the extender. If it’s green, perfect signal. Amber means decent, and red means weak. If the light is red, move the extender closer to your first extender and repeat the WPS process.

Now, that you have learned how to connect multiple Netgear EX7300 extenders with WPS, you should also think of manual setup

Configure Second AC2200 Extender with Mywifiext

Start by plugging your extender into a power outlet that’s halfway between your first extender and the area with weak signal. Make sure it’s in the same room as your router for the initial setup. The Power LED to turn solid green which indicates the extender is booted and working fine.

Link to Extender Network

Start your laptop or computer and go to the WiFi settings. You’ll see a new network “NETGEAR_EXT” will appear. This is your extender’s temporary setup network. Tap and connect to it.

Go into a Browser and Visit to Mywifiext

Now, open any browser (Chrome, Firefox, Safari), and type: mywifiext.net in the address bar and search. If you get a weird error page, try 192.168.1.250 instead. Still not working? Switch devices or check that you’re connected to the extender’s network (NETGEAR_EXT).

Once the setup page loads, you’ll land on the Netgear Genie or Smart Setup Wizard depending on your extender model version.

Set Up the Extender

The setup wizard will guide you through the EX7300 mesh network configuration steps. Follow these:

  1. Click on ‘New Extender Setup’.
  2. Create an admin username and password for the extender.
  3. Choose your existing WiFi network from the list.
  4. Enter your router’s WiFi password.
  5. Now, you can Assign names (SSIDs) for the extended network.

Reconnect Your Devices

When, the setup is completed, the device will reboot and broadcast the new extended network.

Now, go back to your phone or computer, disconnect from NETGEAR_EXT, and connect to your new extended network using the same password you use for your main router.

The Conclusion

Hope, the both the extenders are connected with your router on the second floor. If there is any issues are troubling the connection, you can reach to our experts we are one click away from you.
